Four Lanes Cuboid Kcup Coffee Capsule Filling Sealing Machine
Kcup Filler Sealer Machine
Introduction of the kcup coffee capsule filling sealing machine
Since the establishment of company, we pour ourselves more into
research and development of coffee packaging machine. We have
produced SKP-1, SKP-2, SKP-4, SKP-6, SKP-8 (Compatible nespresso, Dolce gusto, Lavazza Blue, Point, K-CUP,
Kshot, One Cup) automatic Coffee Capsule filling and sealing machine. With good
appearance,high filling accuracy,stable performance,which has won
the favor of customers at home and abroad.The product has obtained
many technical invention patents,through CE,UL
certification,ISO9001 quality management system certification and
got a number of Zhejiang science and technology.
Technical parameters of the kcup coffee capsule filling sealing
machine
|
Machine Construct material | All the product contact parts are stainless steel AISI 304. The
machine is constructed of stainless steel, anodized aluminum mold
and painted iron plate and special plastic |
Certificate | CE, SGS , ISO 9001,UL |
Product | Ground coffee |
Sealing | Die-cutting aluminum foil or roll aluminum Sealing |
Output Capacity | 160 cups/per minute |
Dosing system | Servo driven auger filler |
Filling Weight | 0-20g*n Option |
Filling accuracy | ±0.1g~0.3g |
Installed power | 1 phase 220V 50/60HZ 5KW |
Dimension | 5850*4490*2200mm |
Main features of the kcup coffee capsule filling sealing machine
1)Kcup Coffee Capsule Filling and Sealing Machine form Sunyi
Company, it can use to fill, seal, assemble prefabricated capsules.
2)Easy clean hopper system, change material type in a short time.
3)Running brush and vacuum collect dust machine clean machine's
mold, ensure machine's stable running at non-dust condition.
4)Automatically seal paper or aluminum filter inside of capusule's
bottom, or add plastic filter tray inside of capsule.
5)Destacker for stackable capsules with knives or slides; Direct
loading into stack channels or through buffer system. Sorting
barrel infeed and centrifugal transfer for non-stackable capsules
supplied in bulk.
6)Extremely precise dosing unit to assure correct product weight.
7)All production process with visualization on the touchscreen,
continuously monitoring alll relevant parameters.
8)Special design diagonal roll film unwind system, will have
15%-30% less material consumption compared with conventional
methods.
Usages of the kcup coffee capsule filling sealing machine
1. cups horizontal sent
2. cups detection to make sure all the holes have capsules. no
capsules no filling no sealing.
3. UV lamp to kill the bacteria in the atmosphere
4. visualized hopper auger filling
5. precut sheets station
6. two procedures for heat sealing to make every capsules sealed
well
7. capsules outputting to the conveyor belt
