SKP-1 Coffee Pod Filling Sealing Machine Lavazza Point One Cup
Capsule Filler Sealer
Introduction of the coffee pod lavazza point filling sealing
machine
This coffee pod lavazza point filling sealing machine is suitable
for various kinds of liquid, powder and granule materials, such as
coffee powder, milk powder, tea, yogurt and other food materials.
Roll film cutting and sealing system with high-precision fine tooth
cylinder blade can realize online cutting and sealing at the same
time. The sealing deviation is within 0.1mm. With the
identification mark system, servo motor drives roll film expansion
and dragging precisely.
he remote control system, to a great extent, solves the problem of
international PLC and HMI inconsistency of the software installed
on the PC side. Moreover, the customer can observe the condition of
the parameter value of the machine, the failure rate of the
machine, the production efficiency and so on in real time every day
through the mobile app.
Characters of the coffee pod lavazza point filling sealing machine
| Product name | skp-1 coffee pod lavazza point filling sealing machine |
| Filling accuracy | ±0.15g |
| Filling weight range | 0-20g |
| Filling material | powder |
| Power | AC 110V 220V 380V 7.5kw |
| Drive | Electric-Pneumatic |
| Dimension | 2360(L)x1260(W)x2330(H)mm |
| Control system | PLC remote control system |
| Warranty | one year |
| Port of shipping | shanghai |
| Delivery time | 50 days |
| Quote valid time | 50 days |
| Hopper capacity | 10-25L / 110L |
| Speed | 50-60 pcs per minute |
| Residual oxygen | ＜1% |
| Sealing derivation | ＜0.1mm |
Procedures of the coffee pod lavazza point filling sealing machine
1. vibration plate
2. cut the inner filter
3. auger filling
4. clean the top edge of the pod and tamp the powder
5. roll cutting
6. heat sealing
7. pods output belt
Transportation of the coffee pod lavazza point filling sealing
machine
Using standard export wooden box to pack machine, prohibiting
corrosion and damage during the transportation.
Notes of this trade
1.Delivery time:
After receiving client’s deposit and capsule samples, films, within
30 working days, we will finish the machine.
2.Term of Payments:
At first client shall pay 30% deposit of Purchase order total
amount, then we start to produce machine.
After machine is finished, we will invite client to test machine in
our factory.
After successful checking, client shall pay the remaining 70% of
total amount before shipping.
3.Quote valid time:
50 days
4.Port of Shipment:
Shanghai Ship port.
5.Warranty:
After the machine arrives at client’s factory safely, within 1
year, if any parts damaged in normal use condition, we can send
free spare parts to replace it.
6.After-sale service:
supply training and test in our factory
give operation manual installation and operation video
do after-sale service overseas (client need to pay daily wage 100
USD, and round flight tickets, accommodation);
24-hours online support.
